Portable High Effective Microbial Air Biological Sampler
Portable High Effective Microbial Air Biological Sampler has the advantages of large sampling volume, stable performance,
simple operation, and reaching the advanced level of similar
products. It is an ideal sampling instrument for the detection
departments of pharmaceutical factories, hospitals, biological
products, food processing, public places, etc.
FKC-IB biological air sampler is a kind of high effective air sampler,
which is designed according to the principle of multi jet holes
particle impact and isokinetic sampling.
FKC-IB biological air sampler has large sampling volume, stable
performance and is easy to use.it is an ideal air biological
sampler for medicine plant, hospital and other examination
departments.
Features of microbial air sampler
- Sampling inlet head adopts SUS316 with high precision machining,
up/down diameters of microholes in thehead are same to ensure best
air flow and good bacteria capture effect.
- Optional printer to compare data with culture dish on site
- Optional compressed air sampling accessory to measure no. of
planktonic bacteria in compressed air.
- Convenient operation: easy to change culture dish (φ90*15mm) by
removing sampling inlet head.
- Optional wireless controller
- Complete after-sales service: warranty for 1 year, free-charge for
flow rate calibration, free-charge for software updating
Specification of microbial air sampler
| Sampling flow | 100L / min |
| The sampling port flow rate | 0.38 m/s |
| sampling volume | 0.001-9.999m³ |
| Standard universal Petri dish | Φ90 * 15 |
| Power | DC16.8V |
| Dimensions | Φ120*325 |
| Weight | 3kg |
| Environmental | Temperature: 10--35 ℃; Relative humidity: 10--90% RH; Atmospheric Pressure: 80-110kPa |
| Maximum dust concentration | 100 000 000 / m³@0.5μm or 0.2mg / m³ |
Environmental parameters of microbial air sampler
1. In order to ensure production quality and prevent pollution of
the production environment, production area space must meet
specified environmental standards.
2. The particles and microorganisms in the area is the main control
object, and also need to deal with the environmental temperature,
humidity, fresh air volume, differential pressure, light, sound
level, and other parameters.
3. There are 4 cleanliness classes of pharmaceutical manufacturing
cleanrooms and clean zones.
Accessories of microbial air sampler
1. AC adapter
2. Remote control
3. Petri dish (Φ90×12) 2pcs
