Y09-3016HW Handheld Air Particle Counter For Pharma Cleanroom
Y09-3016HW Handheld Particle Counter is used for particle counting,
with 6 channels of 0.3, 0.5, 1, 3, 5 and 10 μ m particle data
displayed in real time, The particle counter has built-in long-life
laser diode, light collection elliptical lens and unique optical
system to provide concentration measurement range. particle
counter, vacuum pump, isokinetic sampling head, micro processing
circuit, computer interface, all information are displayed on the
LCD screen.
Y09-3016HW Handheld Air Particle Counter is ergonomically designed
to fit in the palm of your hand.The counter is very rugged and
offers true portability while retaining the features and
sensitivity of larger particle counters.
Now it is easy to carry a particle counter right to the point of
interest and obtain accurate results–results you can immediately
print or store to computer. The large color LCD display lets you
see the data easily and err-free.
The specification of Y09-310HW air particle counter
| Outside Dim | 245*128*66 mm3 |
| Display | 4.3inch Touch Screen |
| Weight | 1kg |
| Power Source | DC16.8V |
| Size Channels | 0.3, 0.5, 1, 3, 5, 10 μm |
| Flow Rate | 2.83L/min |
| Sample Time | 1s-99h |
| Cycles | 0-99 |
| Hold Time | 0-999sec |
| Delay Time | 0-99sec |
| Light source | Laser Diode |
| Zero Court | <=10min |
| Class | ISO14644-1:2015/GMP:2015 |
| Coincidence Loss | 5%,2000000ps/cf |
| Operating Time | more than 4hours |
| Location Labels | 0-999 |
| Data Storage | 100000 Samples (Wifi) |
| Environmental | 10degrees celsius-40degrees celsius ; Humidity: 20%-90% RH ;Atmosphere Pressure 86Kpa-106Kpa |
The Feature of Y09-310HW air particle counter
1. Simultaneously sizes and counts particles in six fixed channels
2. Size sensitivities with 0.3μm,0.5μm,1μm,3μm,5μm,10μm
3.0.1CFM(2.83L/min) sample flow rate
4. 4.3 inch color touch screen display 5.External printer optional
6.One year warranty Company Information
