    Injections Testing USP EP Liquid Particle Counter With Color Touch Screen

    Ask Lasest Price
    Brand Name : SUJING
    Model Number : LE100
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 800/per month
    Delivery Time : 5 work days
    • Product Details
    • Company Profile

    Injections Testing USP EP Liquid Particle Counter With Color Touch Screen

    Liquid Particle Counter Injections testing under CP, USP, EP, JP


    The Liquid Particle Counter for USP 788 sizes and counts suspended particulate matter in a wide range of liquids, including parenterals, to meet all current U.S., European and Japanese Pharmacopoeia standards.


    Technical parametersliquid particle counter
    Particle size range2-400 μm
    Particle size channel24
    Maximum detection concentration10000 particles/ml
    Accuracy±10%
    RepeatabilityRSD<2% (particles>1000 per ml, 5ml sample)
    Resolution<10% (U.S.P, ISO 21501)
    Syringe specifications1ml, 5ml, 10ml*, 25ml
    Sampling speed20 ml/min*
    Sample volume accuracy±1%
    Minimum sampling volume0.2ml**
    Sensor material316 stainless steel, quartz glass, PTFE, NBR
    Power supplyAC 100~240V, 50/60HZ
    Mixing methodMagnetic stirrer (speed adjustable)
    Data outputRS232 port; USB; built-in thermal printer
    Display output7 inch LCD color touch screen
    Size320(L)×309(W)×394(H) mm
    Weight11.0 kg
    Operating environmentTemperature 10-40 ℃; RH 0 ~ 95% non-condensing
    Software systemLE-Assistant (optional)

    * Standard configuration

    ** Under 1ml syringe specifications the minimum sampling volume is 0.2ml, under the standard configuration, the minimum sampling volume is 0.4ml


    Overview descriptions of liquid particle counter
    8.Exhaust fan1. Display
    9.heat emission hole2. Door of sample chamber
    10. Power switch3. Thermal printer
    11. AC power outlet and fuse4. Syringe
    12. R232 port5. Sample tube
    13. Sample drain6. LED chamber light
    14. USB port7. Stirrer

    Components of liquid particle counter


    The instrument ×1Power cord ×1
    Fuse ×1Detecting cup ×1
    Stir rod ×1Operation manual ×1
    Drain line tube ×1Testing report ×1
    Touch pen ×1Quality certificate ×1
    Printing paper ×1Warranty card ×1
    Packing list ×1

    Application of liquid particle counter

    • Injections testing under CP, USP, EP, JP and other standards
    • Cleanliness detecting of medical equipment / parts
    • Filtration efficiency detection
    • Laboratory water testing
